EV charger manufacturers integrated AC+DC 120kW Floor Mounted
Commercial Charging Station
1.Descriptions
An additional piece of equipment for recharging and charging
electric vehicles is the integrated off-board DC charger. To manage
the charge of electric vehicles, it offers a charging interface, a
human-machine interface, and other features. It also realizes
charging start and stop, intelligent charging, and other
activities. After secondary development of the embedded single-chip
microcomputer, the main controller is the DC charger. It is a
human-machine platform for staff to perform charging operations and
includes user management, charging interface management, generation
of electronic credentials, networking monitoring, and other
functions.
2.Specifications
Product name | DC EV Charger |
Rated Power | 120kW |
Input voltage | AC323-AC437V |
Input current | ≤228A |
Power factor | ≥0.99 |
Output connector | CCS2 | CHAdeMO |
Charging agreement | DIN70121 | CHAdeMO2.0 |
Basic characteristics |
Protection levels | IP54 |
Startup mode | APP,QR(Customized),RFID, VIN(Customized) |
Communication agreement | OCPP1.6J |
Communication interface | 3G/4G/WIFI |
Charging interface | 2(CCS2+CHAdeMO) |
Power Switching | Support automatic power distribution, minimum switching unit 30kW |
Work efficiency | ≥95% |
Display screen | 7-inch LCD touch screen |
Gun thread | 4.5m |
Ambient Temperature | -20~+50℃ |
Relative humidity | 5%～95%(No dewing) |
Altitude | 2000m |
Standby power loss | ≤ 99W |
Site(W*D*H) | 800mm*600mm*1700mm |
Weight | ≤300kg |
3.FQA
What term do you use when packing?
A: Typically, wooden poles and cardboard shells are used to secure
and carry the merchandise. After receiving your authorization
documents, we can pack the goods in your branded boxes if you have
a patent that has been officially registered.
What is the length of your delivery?
A: Depending on the needs of the visitors, you can set up
international express, air travel, and sea shipping. Recognize FOB,
CFR, CIF, DDP, etc.
Do you test every item you deliver?
A: Indeed, before leaving the factory, every one of our items must
pass rigorous inspection and testing.
